Privacy Function: Privacy door hardware features a locking mechanism on the interior for use on bedroom and bathroom doors where locking is needed. The exterior side features a small pin hole to unlock the door hardware from the outside.
Features:
Solid hand poured cast iron that is hand finished for a unique surface texture
Zinc plated and powder coated for resistance to corrosion, UV weathering and scratches
Intended for both left or right handed door configurations
Installs on doors with 1-3/8″ to 2″ thickness
Hand assembled in USA
Coordinates well with all Ageless Iron products
Does not comply with standards of the Americans with Disabilities Act (ADA)
Covered under a 5 year finish and mechanical warranty
Specifications:
Backset: 2-3/8″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 2″
Handing: Reversible Left or Right
Latch Faceplate: Square Corner
Material: Iron
Handle Projection: 2-5/8″
Construction and Mechanics:
Each piece weighs between 3 and 5 pounds – made from solid, cast iron
Every Ageless Iron product has been life tested for 12 months in Florida exposure for UV resistance and anti-corrosion
Any wear points inside the lockset are factory lubricated for long life
Featuring spring-assisted knobs and levers, the workmanship ensures thousands of worry free usage cycles
Pre-mounting allows for clean and easy installation
Floating spindle allows for minor trim alignment errors
Two screws hold the lock trim securely to the door, providing minimal need for excess tools or expertise
Each set ships with detailed instructions
Design Elements
Rustic powder coated black
Perfect for modern farmhouse to urban loft
Sophisticated black will remain timeless season after season
Additional Ageless Iron Links
View the Manufacturer Warranty
Browse all Ageless Iron Products
Ageless Iron Vale Collection
Specifications
| Product Weight | 3.982 lbs. |
| Backset | 2-3/8" |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8" |
| Edge Bore | 1" |
| Handle Projection | 2.625 in. |
| Material | Iron |
| Thermostat | Rustic, Traditional |
| Handshower | Left, Reversible, Right |
| Latch Faceplate | Square Corner |
| Rosette Shape | Rectangle |
| Trim Design | Vale |
| Handle Style | Knob |
| Handle Material | Metal |
| Concealed Screws | No |
| Function | Privacy |
| Panic Proof | Yes |
| Handle Design | Keep |
| Locking Mechanism | Trim Lock |
| Knob Shape | Round |
| ADA | No |
| Collection | Vale |
| Country Of Origin | USA |
| Made in America | Yes |
| Manufacturer Warranty | 5 Year Finish, 5 Year Mechanical |
| Approved for Commercial Use | No |
| Series | Ageless Iron |
| Fire Rated | No |
| Color | Black Iron |
| Color Tone | Blacks |
