Mounting: Wall
Motor: 3-speed, 1/3 HP, 120V, 1 phase, totally enclosed, ball bearing, permanently lubricated, permanent split capacitor
Controls: Rear mounted pull cord switch
Power Cord: Black, 10′, 3-conductor, SJT type
Coating: Blade, Guard, and Mounts are Powder coated steel
Compliances: UL Listed, OSHA
Oscillation: 90°
Blade Size: 30
Product Dimensions: 33-3/4 L x 25-3/4 W x 38-3/4 H
Secondary support cable included
Additional Air King Links
View the Manufacturer Warranty
Browse all Air King Products
Air King 1/3 HP Industrial Collection
Specifications
Dimensions and Measurements
| Width | 30 in. |
| Product Weight | 46.6 lbs. |
| Cord Length | 72 in. |
| Blade Span | 30 in. |
| CFM | 8780, 5570, 7480 |
Characteristics and Features
| Material | Steel |
| Insulation Type | Wall |
| Control Type | Pull Cord |
Warranty and Product Information
| Approved for Commercial Use | No |
| Collection | 1/3 HP Industrial |
| Certifications | UL |
| OSHA Compliant | Yes |
Electrical and Operational Information
| Wattage | 308 |
| Amperage | 2.8, 2 |
| Horsepower | 0.33 |
| dBA (Low) | 64 |
| dBA (Med) | 70 |
| Decibels (High) | 72 |
| Fan Speeds | 3 |
| RPM (High) | 1075 |
| RPM (Low) | 800 |
