Baldwin Hollywood Hills Full Plate Double Cylinder Keyed Entry Mortise Knob Trim

Double Cylinder Keyed Entry Function: Double cylinder mortise trim requires a key to unlock the mechanism on both the interior and exterior sides of the door. Double cylinder locks can pose a safety hazard in times of emergency due to requiring a key to unlock from the inside; please check local codes before installing.

Features:

Designed by Erinn V., Hollywood Hills is chic and elegant
All mortise lock boxes are to fit standard preparation ANSI A115.1
A luxurious and premium finish maintains its appearance over time
Personalized your mortise lock, cylinder, and choice of either left or right handed depending on door configuration
Includes exterior and interior trim, knob/lever, and spindle
Backsets with 1-1/2″ and 2″ are designed to be used with levers, please contact customer service for lever options
Baldwin offers a Limited Lifetime Mechanical Warranty
Standard finishes have a One Year Limited Warranty when installed in exterior applications and a Five Year Limited Warranty for interior use
Does not meet the standards of the Americans with Disabilities Act (ADA)
Interior comes in same finish as exterior. If split finish is desired please contact customer service
Two keys will be shipped per lock. Three or more items keyed alike will ship a total of 6 keys

Product Technologies:

Solid Brass Construction: Baldwin Estate Series products are constructed from solid brass – providing a more luxurious, higher quality feel than door hardware made with lesser metals. When you hold a Baldwin product in your hand, you will immediately notice the difference that solid brass makes – it is heavier, stronger, and smoother than most of the door hardware on the market today.

Lifetime Finishes™: Baldwin’s multi-patented Lifetime Finishes™ provide unprecedented protection against the effects of weather, normal wear and tear, and even the rigorous test of coastal salt air. By adapting the vapor deposition processed used to create premium gold pens, Baldwin creates a unique surface across your door hardware that is guaranteed to withstand the ravages of time.

Living Finishes: Baldwin Living Finishes, which include Non-Lacquered Brass, Vintage Brass, Oil Rubbed Bronze, and Distressed Oil Rubbed Bronze, are designed to mimic the patina of a well-loved piece of vintage hardware, and as such will change and adapt over time naturally. For those who appreciate the well-worn look of aged door hardware, but still require the strength and durability of a Baldwin finish, Living Finishes are an ideal fit.

Specifications:

Backset: 2-1/2″ or 2-3/4″
Backplate Height: 11-3/4″
Backplate Width: 2-7/16″
Center to Center: 3-7/16″
Latch Faceplate: Square Corner
Door Thickness: 1-3/8″ to 2-1/4″
Handing: Left, Left Hand Reverse, Right, Right Hand Reverse
Interior Handle Style: Knob
Cylinder: 5 Pin
Material: Brass
Product Variations:
6945.FD: Dummy Mortise Knob Set
6945.ENTR: Single Cylinder Mortise Knob Set
6945.DBLC (This Model): Double Cylinder Mortise
6945.ENFD: Combo Pack: Single Cylinder and Full Dummy Knob Sets
