Features:
Features a powerful 686 CFM permanently lubricated and sealed motor that’s specifically designed for continuous use applications
Mounts directly to joists via mounting brackets which makes for an intuitive, straight-forward installation
Compatible with a number of Broan multi-function and time control wall switches (sold separately)
Not recommended for use over bathtubs and showers
Product Technologies:
High Sones: We know that comfort and ambience matter in your bathroom. This fan produces 3.7 sones of sound output while the fan is in operation.
High CFM Capacity: This fan has an impressive 686 CFM (cubic feet per minute) of clearing capacity designed for larger bathrooms. Controlling humidity in your bathroom extends the life of your décor and makes for a more hospitable space to prepare for the day ahead.
Specifications:
CFM: 686
Sones: 3.7
Duct Size: 4-1/2 Inch x 18-1/2 Inch
Housing Width: 12.25 Inches
Housing Length: 21.5 Inches
Housing Depth: 11.75 Inches
HVI Certified: No
UL Listed: Yes
Light Included: No
Product Variations:
L400KL: 375 CFM, for Kitchen Applications
L400L: 406 CFM
L500KL: 472 CFM, for Kitchen Applications
L500L: 481 CFM, for Kitchen Applications
L700L (This Model): 681 CFM
Additional Broan Links
View the Manufacturer Warranty
Browse all Broan Products
Broan LoSone Select Collection
Specifications
| Insulation Type | In-Line |
| Material | Metal |
| Function | In-Line |
| Duct Discharge | Horizontal |
| Grille Finish | No Grille |
| Humidity Sensing | No |
| Night Light | No |
| Collection | High Capacity |
| Approved for Commercial Use | No, Yes |
| Country Of Origin | USA |
| Manufacturer Warranty | 1 Year Limited |
| Certifications | UL |
| Made in America | Yes |
| Energy Star | No |
| Product Weight | 34 lbs. |
| CFM (High) | 686 |
| Duct Size | 4-1/2" x 18-1/2" |
| CFM | 686 |
| Housing Depth | 11.75 in. |
| Hose Length | 21.5 in. |
| Housing Width | 12.25 in. |
| Max Ventilation Area | 624 sq. ft. |
| Wattage | 313 |
| Voltage | 120 |
| Amperage | 2.9 |
| Speeds | 1 |
| Sones | 3.7 |
| Motion Sensor | No |
| Heater Included | No |
| Light Included | No |
| Color | Galvanized Steel |
| Color Tone | Steel Tones |
