Product Features:
102mm(4″) center deckmount faucet
Two Handle
Heavy duty cast brass body
Metal hold-down package
1/2″ NPS shanks
Field installation of spout as rigid or swivel
Teck Lab compression structures
Chrome plated brass renewable seats
Locknuts, lockwashers
1/4″ NPT tailpiece and coupling nuts
Spout: R23 – 152 mm (6″) Angle VB Spout
Outlet: w/ 1/4″ ID Serrated Nozzle Outlet(No Dash or -10 series)
Handle#: C – 70 mm (2-3/4″) ADA compliant Lever Blade Handle-Metal-Color indexed-Vandal resistant screws
Indexed For: CW/HW – Cold & Hot Water(Green & Red)
Product Certifications:
CSA certified
Complies to ASME A112.18.1/CSA B125.1
ADA compliant and meets Handicapped Accessibility Standard ASME A117.1 of less than 5 lbs
Tested and approved under ASSE 1001 and CSA B64.1.1
Additional Delta Links
View the Manufacturer Warranty
Browse all Delta Products
Delta Commercial Collection
Specifications
| Height | 13.24 in. |
| Product Weight | 6.22 lbs. |
| Faucet Centers | 4 in. |
| Max Deck Thickness | 1.75 in. |
| Spout Height | 6.3 in. |
| Spout Reach | 6 in. |
| Material | Brass |
| Faucet Holes | 3 |
| Handle Style | Lever |
| Mounting Type | Centerset |
| Number Of Handles | 2 |
| Pre Rinse | No |
| Pullout Spray | No |
| Valve Type | Ceramic Disc |
| Handle Material | Metal |
| Approved for Commercial Use | Yes |
| Collection | Commercial |
| Country Of Origin | Canada |
| ADA | Yes |
| Made in America | Yes |
| Drain Assembly Included | No |
| Filtering | No |
| Handshower Included | Yes |
| Sidespray | No |
| Valve Included | Yes |
| Color | Chrome |
| Color Tone | Silver Tones |
