Features:
Hot water on demand, with no delay
Flow switch activates heater only when water is running, no standby heat loss
99% efficient, .99 energy factor
Thermostatic control with microprocessor provides precise outlet temperatures
Compact design fits below virtually any sink
Hot or cold water feed
Built in over temp protection
Fitted with 1/2″ compression fittings and electrical entry on the bottom
Covered under Eemax’s 1 year parts and 5 year leaks warranty
Specifications:
Height: 12-1/8″
Width: 18-3/16″
Depth: 4-5/16″
Minimum Flow Rate: 0.7 GPM
Maximum Flow Rate: 4.0 GPM
Temperature (Max): 140°F
Temperature (Min): 100°F
Voltage: 208V
Kilowatts: 24KW
Additional Eemax Links
View the Manufacturer Warranty
Browse all Eemax Products
Eemax Three Phase Collection
Specifications
| Approved for Commercial Use | Yes |
| Collection | Three Phase |
| Series | Three Phase |
| Country Of Origin | USA |
| Manufacturer Warranty | 1 Year Parts, 5 Year Leaks |
| Certifications | ETL, UL |
| Product Variation | Point-Of-Use Water Heater |
| Low Lead Compliant | Yes |
| Outdoor Approved | No |
| Made in America | Yes |
| Uniform Energy Factor | 0.99 |
| Height | 12.14 in. |
| Width | 18.19 in. |
| Depth | 4.32 in. |
| Product Weight | 15 lbs. |
| Water Connection | 1/2" |
| Water Pressure (Max) | 150 PSI |
| Water Pressure (Min) | 25 PSI |
| Activation GPM | 0.7 |
| Maximum Flow Rate | 4 GPM |
| Minimum Flow Rate | 0.7 GPM |
| Power Source | Hardwired |
| Voltage | 208 |
| Wattage | 24000 |
| Fuel Type | Electric |
| Amperage | 67 |
| Temperature (Max) | 140 °F |
| Temperature (Min) | 100 °F |
| Kilowatts | 24 |
| Wire Size | 4 |
| Water Connection Type | Compression |
| Vent Type | Vent Free |
| Heating Technology | Electric Element |
| Indoor Installation | Yes |
