All Emtek items are made to order.
Single Cylinder Function: Single Cylinder function specifies that the deadbolt is thrown by a thumb turn on the interior while the exterior uses a key for locking and unlocking.
Features:
Constructed of solid brass for premium feel and durability
Installs on doors with 1-3/4″ to 2-1/8″ thickness
Includes a selection of round corner or square corner faceplate
Covered under a Limited Lifetime Mechanical and 5 Year Finish Warranty
Two keys will be shipped per lock. Three or more items keyed alike will ship a total of 6 keys
Product Technologies:
Solid BrassConstruction: This product begins with raw bars of solid brass which are heated, and pounded into specially made dies—producing a stronger, more substantial product. The difference between lesser metals and heat forged brass is noticeable the minute you hold it in your hands—solid brass is heavier, smoother, and naturally resists corrosion.
Specifications:
Backset: 2-3/4″ or 2-3/8″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/4″ to 3″
Trim Width: 2-1/2″
Trim Height: 2-1/2″
Latch Faceplate: Square Corner, Round Corner
Material: Brass
Cylinder: 5 Pin Schlage C
Product Variations:
8580: One Sided Deadbolt
8426 (This Model): Single Cylinder Deadbolt
8326: Double Cylinder Deadbolt
Additional Emtek Links
View the Manufacturer Warranty
Browse all Emtek Products
Emtek Urban Modern Collection
Specifications
| Material | Brass |
| Thermostat | Modern |
| Function | Keyed Entry |
| Cylinder Type | Single Cylinder |
| Latch Faceplate | Round Corner, Square Corner |
| Rosette Shape | Square |
| Solid Construction | Solid Brass |
| Concealed Screws | No |
| Cylinder | 5 Pin Schlage C |
| Keyway | C |
| Locking Mechanism | Thumbturn |
| Removable Core | No |
| Collection | Urban Modern |
| Approved for Commercial Use | No |
| Manufacturer Warranty | 5 Year Finish, Limited Lifetime Mechanical |
| Series | Urban Modern |
| Backset | 2-3/4", 2-3/8" |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-3/4", 1-7/8", 2", 2-1/2", 2-1/4", 2-1/8", 2-3/4", 2-3/8", 2-5/8", 2-7/8", 3" |
| Edge Bore | 1" |
| Interior Height | 2.5 in. |
| Interior Width | 2.5 in. |
| Exterior Height | 2.5 in. |
| Exterior Projection | 0.5 in. |
| Exterior Width | 2.5 in. |
| Cylinder Included | Yes |
| Color | Flat Black |
| Color Tone | Blacks |
