Emtek Argos Privacy Brass Leverset with Concealed Screws

All Emtek items are made to order

Privacy Function: Privacy door hardware features a locking mechanism on the interior for use on bedroom and bathroom doors where locking is needed. The exterior side features a small pin hole to unlock the door hardware from the outside. Emergency release tool included (small pin)

Features:

Solid brass rosette and housing give a long lasting and durable beauty
Reversible handing for easy installation
Emtek’s CF mechanism features concealed screws for a cleaner look; and a reduced 28° latch for a smoother and easier opening cycle
Comes standard with a 2-3/8″ latch with the option for 2-3/4″ latch
CF Mechanism is only available with square corner latch faceplates
CF mechanism knob and leversets are backed by Emtek’s CF Mechanism Limited Lifetime warranty

Specifications:

28 Degree Latch: Yes
Backset: 2-3/4″, 2-3/8″
Concealed Screws: Yes
Cross Bore: 2-1/8″
Door Thickness: 1-1/4″, 1-3/8″, 1-1/2″, 1-5/8″, 1-3/4″, 1-7/8″, 2″, 2-1/8″, 2-1/4″, 2-3/8″, 2-1/2″, 2-5/8″, 2-3/4″, 2-7/8″, 3″
Edge Bore: 1″
Handing: Left, Reversible, Right
Latch Faceplate: Square Corner
Lever Length: 5″
Projection: 2-1/4″

Product Variations:

C505AG: Argos Dummy Brass Lever Set with CF Mechanism
C510AG: Argos Passage Brass Leverset with CF Mechanism
C520AG (This Model): Argos Privacy Brass Leverset with CF Mechanism
