Passage Function: Passage door hardware has no locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a lock isn’t needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.
Features:
Hand forged from solid brass and genuine lead crystal
Handing is reversible for left or right handed doors
Easily installs on standard prepared doors
Includes a 2-3/4″ backset and square corner latch
Covered by a Limited Lifetime Mechanical and 10 Year Finish Warranty
Does not fulfill criteria of the American’s with Disabilities Act (ADA)
Hand assembled in the United States
Product Technologies:
Solid Brass Construction: Grandeur rosettes and backsets are forged from a solid piece of brass. This process yields a denser, stronger and higher quality product that can better display intricate designs than casted door hardware.
Genuine Crystal: Grandeur crystal knobs are constructed of at least 24% lead crystal. Crystal is both stronger and more reflective than glass; displaying a bright sparkle and rainbow prism effect.
Specifications:
Backset: 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible, Left or Right
Handle Height: 2-3/4″
Handle Width: 1-3/4″
Handle Projection: 3-1/8″
Trim Height: 8-5/8″
Trim Width: 2-5/8″
Latch Faceplate: Square Corner
Material: Brass, Crystal
Additional Grandeur Links
View the Manufacturer Warranty
Browse all Grandeur Products
Grandeur Provence Crystal Collection
Specifications
| Product Weight | 4.5 lbs. |
| Handle Height | 2.7 in. |
| Backset | 2-3/4" |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8" |
| Edge Bore | 1" |
| Handle Projection | 2.59 in. |
| Handle Width | 1.7 in. |
| Trim Height | 8.625 in. |
| Trim Width | 2.625 in. |
| Manufacturer Warranty | 10 Year Finish, Limited Lifetime Mechanical |
| Collection | Provence Crystal |
| Approved for Commercial Use | No |
| Series | Windsor |
| ADA | No |
| Country Of Origin | USA |
| Fire Rated | No |
| Material | Brass, Crystal |
| Thermostat | Transitional |
| Handshower | Left, Reversible, Right |
| Solid Construction | Solid Brass |
| Handle Material | Crystal |
| Concealed Screws | No |
| Function | Passage |
| Handle Design | Provence Crystal |
| Latch Faceplate | Square Corner |
| Rosette Shape | Rectangle |
| Knob Shape | Egg |
| Trim Design | Windsor |
| 28 Degree Latch | No |
| Color | Antique Pewter |
| Color Tone | Greys |
