Grundfos 230S752 Pump with a Rated Flow of  229 US GPM, a Flow Range of 31.7 .. 316 US GPM and Stainless Steel Construction

230S752 Pump with a Rated Flow of  229 US GPM, a Flow Range of 31.7 .. 316 US GPM and Stainless Steel Construction

Product name:  230S752

Technical:

Speed for pump data  3450 rpm
Rated flow:  229 US gpm
Flow range  31.7 .. 316 US gpm
Max flow:  316 US gpm
Rated head:  78.7 ft
Shaft seal for motor:  CER/CARBON
Approvals on nameplate:  CE,CSACUS
Curve tolerance:  ISO9906
Pump Number:  15BH0002
Stages:  2

Material:

Pump:  Stainless steel
Impeller:  Stainless steel
Motor:  Stainless steel

Installation:

Maximum ambient pressure:  870 psi
Pump outlet:  3″ NPT
Motor diameter:  6 inch
Minimum borehole diameter:  6″ mm
Motor Number:  78285541
Thermal protect:  external
Model:  A
Valve:  pump with built-in non-return valve

Liquid:

Max liquid temperature at 0.15 m/sec  86 °F
Built-in temperature transmitter  yes

Electrical Data:

Motor type:  MS6
Applic. motor:  NEMA
Rated power – P2:  7.5 HP
KVA code:  H
Main frequency:  60 Hz
Rated voltage:  3 x 208-230 V
Start. method:  direct-on-line
Starter:  1
Service factor:  1.15
Rated current:  27.0-23.6 A
