Grundfos 800S7503A Multistage Submersible Pump with a Rated Flow of 801 US GPM, a Rated Head of 259 Ft and Stainless Steel Construction

800S7503A Multistage Submersible Pump with a Rated Flow of 801 US GPM, a Rated Head of 259 Ft and Stainless Steel Construction

800S7503A Multistage submersible pump for raw water supply, groundwater lowering and pressure boosting. The pump is suitable for pumping clean, thin, non-aggressive liquids without solid particles or fibers. The pump is made entirely of Stainless steel DIN W.Nr. DIN W.Nr. 1.4301 and suitable for horizontal and vertical installation. The pump is fitted with a built-in non-return valve.

Technical:

Speed for pump data: 3450 rpm
Rated flow: 801 US gpm
Rated head: 259 ft
Curve tolerance: ISO9906

Material:

Pump: Stainless steel
Pump: DIN W.-Nr. 1.4301
Pump: AISI 304
Impeller: Stainless steel
Impeller: DIN W.-Nr. 1.4301
Impeller: AISI 304

Installation:

Pump outlet: 6″ NPT
Motor diameter: 8 inch
Minimum borehole diameter: 10″ mm

Liquid:

Maximum liquid temperature: 104 °F

Electrical Data:

Power (P2) required by pump: 73.8 HP
Start. method: direct-on-line
