Grundfos CR 56 AFGJAE HQQE Vertical, Non-self Priming, Multistage, Inline, Centrifugal Pump with a Maximum Liquid Temperature of 248°F, a Rated Flow of 30.4 US GPM, a Rated Head of 148 Ft and Cast Iron Construction

CR 56 AFGJAE HQQE Vertical, Non-self Priming, Multistage, Inline, Centrifugal Pump with a Maximum Liquid Temperature of 248°F, a Rated Flow of 30.4 US GPM, a Rated Head of 148 Ft and Cast Iron Construction

CR 56 AFGJAE HQQE Vertical, non-self priming, multistage, inline, centrifugal pump for installation in pipe systems and mounting on a foundation. The pump has the following characteristics: Impellers and intermediate chambers are made of Stainless steel DIN W.Nr. DIN W.Nr. 1.4301. Pump head and base are made of Cast iron. The shaft seal has assembly length according to DIN 24960. Power transmission is via cast iron split coupling. Pipe work connection is via ANSI flanges. The motor is a 3 phase AC motor.

Technical:

Speed for pump data: 3452 rpm
Rated flow: 30.4 US gpm
Rated head: 148 ft
Shaft seal: HQQE
Approvals on nameplate: ANSI/NSF61

Material:

Pump housing: Cast iron
Pump housing: EN-JL1030
Pump housing: ASTM 25 B
Impeller: Stainless steel
Impeller: DIN W.-Nr. 1.4301
Impeller: AISI 304

Installation:

Maximum ambient temperature: 104 °F
Max pressure at stated temperature: 363 psi / 250 °F
Max pressure at stated temperature: 363 / -4 psi/°F
Flange standard: ANSI
Pipe connection: 1 1/4″
Pressure stage: CLASS 300
Flange size for motor: 56C

Liquid:

Liquid temperature range: -4 .. 248 °F

Electrical Data:

Motor type: 90CC
Number of poles: 2
Rated power – P2: 2 HP
Power (P2) required by pump: 2.01 HP
Main frequency: 60 Hz
Rated voltage: 3 x 208-230/460 V
Service factor: 1.15
Rated current: 5.70-5.40/2.70 A
Starting current: 810-900 %
