Grundfos UPS 5040 F Canned Rotor Pump with a Rated Voltage of 1 X 230 and Cast Iron Construction

UPS 5040 F Canned Rotor Pump with a Rated Voltage of 1 X 230 and Cast Iron Construction

UPS 5040 F The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid. In order to avoid problems in connection with disposal, great importance has been attached to using as few different materials as possible. The pump is characterized by: 3speed motor. Ceramic radial bearings. Carbon axial bearing. Stainless steel rotor can, bearing plate and rotor cladding. Aluminum alloy stator housing. Cast iron pump housing. Stator with built-in thermal switch. The motor is a 1 phase motor. The pump is supplied with a standard module in the terminal box. The standard module is to be connected to the mains supply via external contactor.

Technical:

Maximum operating pressure: 145 psi
Approvals on nameplate: CUL

Material:

Pump housing: Cast iron
Pump housing: EN-JL1040
Pump housing: ASTM 35 B – 40 B
Impeller: Stainless steel
Impeller: DIN W.-Nr. 1.4301
Impeller: AISI 304

Installation:

Range of ambient temperature: 32 .. 104 °F
Maximum operating pressure: 145 psi
Flange standard: USA
Type of connection: F
Pipe connection: 50
Pressure stage: 145 psi
Port-to-port length: 14″ mm

Liquid:

Liquid temperature range: 14 .. 248 °F

Electrical Data:

Power input in speed 1: 204 W
Power input in speed 2: 244 W
Max. power input: 285 W
Main frequency: 60 Hz
Rated voltage: 1 x 230 V
Current in speed 1: 1.1 A
Current in speed 2: 1.3 A
Current in speed 3: 1.32 A
Cos phi in speed 1: 0,81
Cos phi in speed 2: 0,82
