TWX LED wall-Pack family, a ground-up design that has the low initial cost customers demand while providing superior performance and a traditional form. The TWPX3 LED is energy efficient saving up to 84% in energy costs when replacing a metal halide luminaire. The TWPX3 LED ALO luminaires can replace anything from a 100-Watt to 400-Watt metal halide luminaire.
Features:
The Adjustable Light Output (ALO) feature allows the contractor to set the light output during installation, to a level perfectly suited for the job site
Includes a polycarbonate lens
Constructed from cast aluminum
Rated for use in wet locations
Title 24 compliant
Covered under a 5 year limited manufacturer warranty
Dimensions:
Height: 14″
Width: 18″
Extension: 5″
Product Weight: 13 lbs
Electrical Specifications:
Wattage: 108 Watts
Bulb Type: LED
Voltage: 120-277 Volts
Color Temperature: 5000K
Color Rendering Index: 70 CRI
Lumens: 13200
Average Hours: 100000
Additional Lithonia Lighting Links
View the Manufacturer Warranty
Browse all Lithonia Lighting Products
Lithonia Lighting Contractor Select TWX Collection
Specifications
| Height | 14 in. |
| Nominal Width | 18 in. |
| Product Weight | 13 lbs. |
| Width | 18 in. |
| Extension | 5 in. |
| Nominal Height | 14 in. |
| ADA | No |
| Collection | Contractor Select TWX |
| Country Of Origin | Mexico |
| Manufacturer Warranty | 5 Year Limited |
| Location Rating | Wet Location |
| Title 20 Compliant | Yes |
| Title 24 | Yes |
| Material | Aluminum |
| Bulb Base | Integrated LED |
| Bubbler Type | LED |
| Bulb Visible | No |
| Dimmable | Yes |
| LED | Yes |
| Light Direction | Ambient Lighting |
| Number of Light Source(s) | 1 |
| Photocell | No |
| Shade Color | Clear |
| Shell Material | Synthetic |
| Showerhead Shape | Rectangle |
| Color Temperature | 5000K |
| Vapor Tight | No |
| Bulb Included | Yes |
| Shade | Yes |
| Power Source | Hardwired |
| Voltage | 120, 277 |
| Wattage | 108 |
| Color Rendering Index (CRI) | 70 |
| Lumens | 13200 |
| Average Hours | 100000 Hours |
| Color | Textured Dark Bronze |
| Color Tone | Brass Tones |
