Package Includes:
Vitreous china wall mounted urinal
.125 GPF exposed, sensor activated, Royal Optima flushometer
Flushometer Features:
Covered by Sloan’s 3 Year Limited Warranty
Permex synthetic rubber diaphragm with dual filtered fixed bypass
Optima EL-1500 self-adaptive infrared sensor with indicator light
Chrome plated wall cover plate (for 2-gang electrical box) with vandal resistant screws
3/4″ I.P.S. screwdriver Bak-chek® angle stop
Free spinning vandal resistant stop cap
Adjustable tailpiece
High back pressure vacuum breaker flush connection with one-piece bottom hex coupling nut, spud coupling and flange for 3/4″ top spud
Sweat solder adapter with cover tube and cast wall flange with set screw
High copper and low zinc brass castings for de-zincification resistance
Non-hold-open integral solenoid operator, fixed metering bypass and no external volume adjustment to ensure water conservation
Flush accuracy controlled by cID technology
Diaphragm, stop seat and vacuum breaker are constructed from Permex rubber compound for chloramine resistance
Urinal Features:
Covered by Sloan’s 3 Year Limited Warranty
Constructed from vitreous china
For wall-mounted installations
Washdown flushing action
3/4″ I.P.S. top spud inlet
2″ NPT outlet flange
All mounting hardware included
Integral flushing rim
100 % factory flush tested
Compatible with Jay R. Smith carrier 0636 or 0637
Additional Sloan Links
View the Manufacturer Warranty
Browse all Sloan Products
Specifications
| Height | 20.75 in. |
| Product Weight | 79 lbs. |
| Width | 17.25 in. |
| Depth | 14.25 in. |
| Gallons Per Flush | .125 |
| Spud Size | .75 in. |
| Spud Inlet Size | .75 in. |
| ADA | Yes |
| Commercial Warranty | 3 Year Limited |
| Manufacturer Warranty | 3 Year Limited |
| Approved for Commercial Use | Yes |
| CA Drought Compliant | Yes |
| WaterSense Certified | Yes |
| ASSE Code | A112.19.2 |
| Certifications | ANSI, ASME, CSA |
| Product Variation | Electronic Flushometer |
| CSA Code | B45.1 |
| Eco Friendly | Yes |
| TX Drought Compliant | Yes |
| Material | Vitreous China |
| Insulation Type | Wall Mounted |
| Water Efficient | Yes |
| Control Type | Electronic |
| Spud Placement | Top |
| Flushometer Valve Included | Yes |
| Flushometer Included | Yes |
| Color | White |
| Color Tone | Whites |
