Sloan High Efficiency Urinal features a battery powered, sensor-operated G2 Optima Plus® Flushometer and a vitreous china urinal fixture.

Eco Friendly Urinal (0.25 gpf) Complete HEU system with Battery Powered, Sensor Operated Sloan EcOS(R) urinal Flushometer with Smart Sense Technology(tm) and vitreous china urinal.

Quiet, exposed, chrome plated urinal Flushometer for either left or right hand supply

Flushometer Features:

PERMEX Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass
OPTIMA EL-1″0 Self-Adaptive Infrared Sensor with Indicator Light
Non-Hold-Open Integral Solenoid Operator
Chrome Plated Wall Cover Plate (for 2-gang Electrical Box) with Vandal Resistant Screws
3/4″ I.P.S. Screwdriver Bak-Chek Angle Stop
Free Spinning Vandal Resistant Stop Cap
Adjustable Tailpiece
High Back Pressure Vacuum Breaker Flush Connection with One-Piece Bottom Hex Coupling
Nut, Spud Coupling and Flange for 3/4″ Top Spud
Sweat Solder Adapter w/Cover Tube and Cast Wall Flange w/Set Screw
High copper, low zinc brass castings for dezincification resistance
Non-Hold-Open Integral Solenoid Operator, Fixed Metering Bypass and no external volume adjustment to ensure water conservation
Flush accuracy controlled by CID technology
Diaphragm, Stop Seat and Vacuum Breaker to be molded from PERMEX rubber compound for chloramine resistance
Valve Body, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1.7, ANSI/ASME A1.5 and Military Specification V-291.

Urinal Features:

Wall hung vitreous china
Washdown flushing action
3/4″ I.P.S. top spud inlet
2″ NPT outlet flange
All mounting hardware included
Integral flushing rim
100 % factory flush tested
compatible with Jay R. Smith carrier 0636 or 0637

ADA compliant

Automatic:

Sloan EcOS(R) Electronic Flushometers are activated via multi-lobular infrared sensor. By detecting user
presence and duration, the Sloan EcOS(R) Smart Sense Technology(tm) will determine the proper flush volume for unequalled water efficiency.

Functional & Hygienic:
Touchless, sensor operation eliminates the need for user contact to help control the spread of infectious
diseases. The Sloan EcOS(R) Flushometer is also provided with an optional Override Button to allow a
“courtesy flush” for individual user comfort.

Economical:
The Sloan EcOS(R) Flushometer is equipped with Smart Sense Technology(tm) which applies extended range and logic techniques to significantly reduce water usage in high use urinal applications;such as when a continuous line of people, also known as a queue. forms. In fact during continuous queue, regardless the number of users, the maximum amount of water used is only 2.0 gallons. Please contact Sloan for specific Details.

Warranty:
3 year (limited)
